Machine vision in focus
| Sensor | 4K |
| Image Sensor | CMOS |
| Shutter | Global |
| Resolution | 4096 × 2 |
| Line Rate | 92 kHz |
| Bit Depth | 12 |
| Mono/Color | Color |
| Pixel Size | 7 μm × 7 μm |
| Pixel | 4096×2 |
| S/N Ratio | 39.4 DB |
| Dynamic Range | 66 dB |
| Image Format | BayerRG8,RGB8 |
| Binning | Support |
| ROI | Support |
| X Flip | Support |
| Gain | 1–32 |
| White Balance | Support |
| Gamma | From 0 to 4, support LUT |
| Exposure Time | 4 us–100 ms |
| Trigger Mode | Software Trigger/Hardware Trigger/Free Run Mode |
| FPN | Support |
| User Setting | Support two sets of user-defined configurations |
| Pixel Clock | 34/51/64/85 MHz |
| Port | CameraLink |
| Lens Mount | M42 |
| Power Supply | 12V～24 VDC power supply |
| Power Consumption | 4.5 W |
| Product Dimensions | 62 mm × 62 mm × 33.7 mm (Not including rear case connector) |
| Net Weight | 200 g |
| Storage Temperature | -30℃~+80℃ |
| Operating Temperature | -30℃~+50℃ |
| Binning | Support |
|---|---|
| Bit depth | 12 |
| Dynamic range | 66 dB |
| Exposure time | 4 us-100 ms |
| Fpn | Support |
| Gain | 1-32 |
| Gamma | From 0 to 4，support LUT |
| Image format | BayerRG8,RGB8 |
| Image sensor | CMOS |
| Lens mount | M42 |
| Line-rate | 92 kHz |
| Pixel | 4096×2 |
| Pixel size | 7 um x 7 um |
| Port | CameraLink |
| Power consumption | 4.5 W |
| Power supply | 12V~24 VDC power supply |
| Resolution | 4096 x 2 |
| Roi | Support |
| Sensor | 4K |
| Shutter | Global |
| Storage temperature | -30℃~+80℃ |
| Trigger mode | Software Trigger/Hardware Trigger/Free Run Mode |
| User setting | Support two sets of user-defined configurations |
| White balance | Support |
| X flip | Support |
| Mono-color | Color |
| S/n ratio | 39.4 DB |
| Pixel clock | 34/51/64/85 MHz |
