Описание
- ??????????1Gbps???????????100m?
- 128MB ?????????????????????
- ??????/????/??????????
- ??????,???,?????,???????ISP ???
- ????????????,ROI,Binning,???AutoFunction??
- ??GigE Vision V2.0???GenICam??
- ??CE,RoHS??
Dimensions
_29x29x42%E5%B0%8F%E9%9D%A2%E9%98%B5%E7%9B%B8%E6%9C%BA_%E7%BD%91%E5%8F%A3%E5%B0%BA%E5%AF%B8%E5%9B%BE19.png)
AE7500MG000
| Sensor | IMX264 |
| Image Sensor | 2/3″CMOS |
| Shutter | Global |
| Resolution | 2448 x 2048 |
| Frame Rate | 24 fps |
| Bit Depth | 12 |
| Mono/Color | Mono |
| Pixel Size | 3.45 ?m x 3.45 ?m |
| Pixel | 5.0 MP |
| S/N Ratio | 40 dB |
| Dynamic Range | 73 dB |
| Image Format | Mono8/10/10Packed/Mono12/Mono12Packed |
| Binning | off/onebytwo/twobyone/twobytwo/onebyfour/fourbyone/twobyfour/fourbytwo/fourbyfour/ThreebyThree/onebySix/SixbyOne/SixbySix |
| ROI | Support |
| X Flip | Support |
| Y Flip | Support |
| Gain | 1?32X |
| Gamma | From 0 to 3.99998, support LUT |
| Exposure Time | 1 ?s?10 s |
| Trigger Mode | Software Trigger/Hardware Trigger/Free Run Mode |
| SPC | Support |
| user Setting | Support three sets of user-defined configurations |
| Image Buffer | 128MB |
| Port | GigE, PoE |
| GPIO Interface | 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output |
| Lens Mount | C-mount |
| Power Supply | PoE/ DC 9V~24V power supply via Hirose interface |
| Power Consumption | 12 V?2.8W |
| Product Dimensions | 29 mmx29 mmx42 mm (not including lens mount and rear case connector) |
| Net Weight | 98 g |
| Storage Temperature | -30?~+80? |
| Operating Temperature | 0?~+50? |
Допълнителна информация
| Binning | off/onebytwo/twobyone/twobytwo/onebyfour/fourbyone/twobyfour/fourbytwo/fourbyfour/ThreebyThree/onebySix/SixbyOne/SixbySix |
|---|---|
| Bit depth | 12 |
| Dynamic range | 73 dB |
| Exposure time | 1 us~10 s |
| Frame rate | 24 fps |
| Gain | 1~32X |
| Gamma | From 0 to 3.99998, support LUT |
| Gpio interface | 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output |
| Image buffer | 128MB |
| Image format | Mono8/10/10Packed/Mono12/Mono12Packed |
| Image sensor | 2/3"CMOS |
| Lens mount | C-mount |
| Pixel | 5.0 MP |
| Pixel size | 3.45 um x 3.45 um |
| Port | GigE, PoE |
| Power consumption | 12 V≈2.8W |
| Power supply | PoE/ DC 9V~24V power supply via Hirose interface |
| Resolution | 2448 x 2048 |
| Roi | Support |
| Sensor | IMX264 |
| Shutter | Global |
| Spc | Support |
| Storage temperature | -30℃~+80℃ |
| Trigger mode | Software Trigger/Hardware Trigger/Free Run Mode |
| User setting | Support three sets of user-defined configurations |
| X flip | Support |
| Y flip | Support |
| Mono-color | Mono |
| S/n ratio | 40 dB |
